Radiator
Road Roller Radiator
In case you do not find the type or model in the website
We can customized according to your request.
Contact Now
Contact Now
- TEL:0086-21-35324169
- FAX:0086-21-35324166
- Email:sales@shenglintec.com
- WhatsApp:0086 13916147965
- Mob:0086 13916147965
The company has various brands of construction machinery radiator manufacturing technology, supporting power ranging from 15 horsepower to 1000 horsepower. The models include concrete mixers, rotary drilling rigs, trenchless directional drilling rigs, down-the-hole drilling rigs, road milling machines, etc. , And can design special-purpose construction machinery radiators for licenses according to customer requirements.
Product Features:
XGSX03-22 is a supporting product for construction machinery road rollers, which are used in the cooling system of the main engine. When working, the water radiator and the oil radiator exchange heat through the medium of water and oil, fins and heat exchangers to ensure their normal operating temperature; the intercooler will increase the charging efficiency in the engine and increase the fuel efficiency, thereby reducing Improve engine efficiency as a whole to ensure normal operation of the main engine.
Scope of application:
Maximum allowable working pressure 100KPa
The maximum allowable antifreeze temperature is 98℃
The main parameters of the product:
Installation size: 750*182
Dimensions: 880*760*390
Engine rated power: 98kW
(Water radiator) core size: 640*693*90
(Water radiator) Heat dissipation area: 34m2
(Oil radiator) core size: 293*650*100
(Oil radiator) Heat dissipation area: 14.5m2
(Intercooler) Core size: 307*700*80
(Intercooler) Heat dissipation area: 15m2
Excavators, loaders, road rollers, graders, pavers, rock drills, cranes.
