Features
Technical Data
Application

Features:
1. Efficiency and energy conservation
2. Green energy and environment-friendly
3. Safety and reliability
4. Durability
5. Easy installation
6. All-weather application
7. Intelligent control
8. Multi-point water supply
9.In summer, it draws indoor heat and releases it to soil
10.In winter, it draws heat of soil for indoor heating after temperature rise

Specifications:

Swimming pool heat pump specifications
Model	SLG20D	SLG30D	SLG50D	SLG60D	SLG100D	SLG200D
Input power (KW)	1.84	2.98	4.6	5.4	9.2	19
Heating capacity (KW)	7	14	20	24	38	78
Rated voltage (V)	220	220/380	380	380	380	380
Rated current (A)	8	6月13日	9	12	18	32
Rated frequency (HZ)	50/60
Outlet water Max temp (℃)	35/45
Water flow (L/H)	2000	3600	5500	7000	11000	22000
Pipe Size	DN50	DN50	DN50	DN50	DN63	DN75
Dimensions (mm)	1050350650	1120490790	11204901260	11204901260	14507601060	19909802080
Packing dimensions (mm)	1120400800	1200520870	12005201440	12005201440	15208001230	206010502230
Weight (KG)	75	105	170	180	280	550
Noise (Db)	≦40	≦50	≦55	≦60	≦70	≦75
Leve of security	IP×4
Electric shock protection grade	1 Grade
Refrigerant	R417A/R407C/R404A/R410A/R22/R134A
Compressor	Panasonic	Panasonic/ Copeland	Copeland
Condenser: Titanium tube heat exchanger
Evaporator: Internal thread copper pipe and wave hydrophilic aluminum foil
Throttle unit: Electronic expansion valve/ Thermal expansion valve/ Capillary
Body: Spray coating metal plate (Stainless steel body should add price)

Quality management

Trial manufacturing center and lab are fitted with leading softwares, hard-wares and testing equipment.
The technical indicator and testing range of the national-level air conditioning testing center are higher than those of the national testing levels.
Factors and processes influencing the operation of the products are strictly controlled in Bright, and our Bright also carries out a wholeset of rigorous
and precise manufacturing crafts manship requirements to guarantee the superior quality.

All procedures are totally controlled by the softwares. Thus, the human factors are eliminated in the quality management.
Spare parts with defects will not be used and the unqualified products will not be packed up.
