Fan
Double Inlet Centrifugal Blowers
MODEL VOLTAGE (V) FREQUENCY (HZ) Current draw (A) Power input (W) SPEED (r/min) Air flow (m/h) Static pressure (Pa) CAPACITOR (F) WEIGHT (kg) DYF4D-250-QD1a 400/230 50 1.68 820 1300 2620 0 14 DYF4D-250-QD1b 60 1.26 730 1580 1960 300 DYF4E-250-QD2a 230 50 2.51 590 1250 2030 0 10/400 14 DYF4E-250-QD2b...
We're here to help
Easy ways to get the answers you need.
Contact Now
Contact Now
- TEL:0086-21-35324169
- FAX:0086-21-35324166
- Email:sales@shenglintec.com
|
MODEL
|
VOLTAGE
(V) |
FREQUENCY
(HZ) |
Current draw
(A) |
Power input
(W) |
SPEED
(r/min) |
Air flow
(m³/h) |
Static pressure
(Pa) |
CAPACITOR
(μF) |
WEIGHT
(kg) |
|
DYF4D-250-QD1a
|
400/230
|
50
|
1.68
|
820
|
1300
|
2620
|
0
|
|
14
|
|
DYF4D-250-QD1b
|
60
|
1.26
|
730
|
1580
|
1960
|
300
|
|
||
|
DYF4E-250-QD2a
|
230
|
50
|
2.51
|
590
|
1250
|
2030
|
0
|
10/400
|
14
|
|
DYF4E-250-QD2b
|
60
|
3.15
|
700
|
1475
|
1900
|
100
|
10/400
|
||
|
DYF6E-250-QD3a
|
230
|
50
|
1.15
|
230
|
880
|
1500
|
0
|
6.0/400
|
12
|
|
DYF6E-250-QD3b
|
60
|
1.42
|
300
|
930
|
1610
|
0
|
6.0/400
|
Applications
♦ Industrial boiler blowing air, Industrial boiler inducing air, Industrial boiler waste gas dust collecting.
♦ Industrial kilns
♦ Ventilating
♦ Cooling and heat dissipation
♦ Air purification and industrial waste gas treatment, Industrial dust collector.
♦ Air purification of hazardous working environment (Paper making production line, Electrolytic aluminium production line, Textile mill).
♦ Metal smelting
♦ Gas and materials delivery
♦ Recovery of industrial waste gas, Supply air and drying of food and drug production line.
