Cooling Tower
Data Center Countercurrent Closed Cooling Tower
  • Data Center Countercurrent Closed Cooling Tower
  • Data Center Countercurrent Closed Cooling Tower
  • Data Center Countercurrent Closed Cooling Tower
  • Data Center Countercurrent Closed Cooling Tower

Data Center Countercurrent Closed Cooling Tower

In case you do not find the type or model in the website We can customized according to your request.
Contact Now
  • Features
  • Technical Data
  • Application
  • Certification
  • Part List
  • Reference

The LBH design and structure features


The use of cross-flow cooling method, the water rate is very low.
Large interior space, maintenance is very convenient.
Fully enclosed circulation to prevent clogging caused by debris
Heat exchange using building block stacking method, can be installed and removed layer
No need for sink, small footprint, easy to access
Automatic digital display temperature control, energy saving and environmental protection
Simple operation and low maintenance cost.

Product Description
LBH Series closed-type cooling tower is updated and improved by absorbing the most advanced heat exchange technology at home and abroad, and a kind of effective heat exchanging equipment is developed.

Product Performance

LBH products using the combination of water and air and mixed flow two times heat exchange coil and PVC packing technology, to achieve efficient heat exchange. As the air and spray water flow through the coil, the sprinkler to the maximum extent possible to cover the surface of the coil to ensure that the surface of the coil is completely moist. Compared with the reverse structure of feng shui, it greatly reduces the formation of dry point and scale of the coil wall.

Structural Characteristics

1, high-efficiency spray water circulation system
The use of the latest developed ABS special spray guess, with a large amount of spray, water distribution uniformity, not clogging, and other advantages, reasonable water pipe spray height and nozzle layout can be in the outer wall of the coil tube to form a uniform water film, and avoid wall flow. Spray water circulating system special waterproof scale device, reduce corrosion, increase heat exchange effect. The use of outdoor circulating water pump. Reduce energy consumption and reduce maintenance.


2, high efficiency and low noise fan
Second, high-efficiency and low-noise fan using the National Invention Award for the broad-leaved, large chord length, space-twisted aluminum alloy cooling tower dedicated fan, with high efficiency, small vibration, low noise, energy saving. The fan and the motor adopt the direct-linking type, does not need to decelerate, the maintenance is convenient, the motor uses the outdoor type high temperature resistant sealed motor

3, solid corrosion-resistant tower body
In order to make the closed cooling tower in the harshest environment to maintain normal operation, the structure of the tower body and the water-collecting chassis are all made of stainless steel plate folding, the tower plate and fan fan cylinder using xing corrosion of FRP components, closed cooling tower all connectors are stainless steel materials.

4. Efficient water-collecting device
Using the latest FRP material production of three-dimensional water collector, air resistance is small, high water efficiency, in the cycle of more than 999%. To facilitate the internal maintenance of the cooling tower, the water collector is designed as a detachable type

Model

Cooling capacity

Cooling flow

Working pressure

Spray pump

Fan

Inlet and outlet pipe

Overall dimension mm

Weight Kg

Kcal/h

m3/h 5℃ 28WB

Mpa

Input power kw

Flow m3/h

Input power kw

Flow m3/h

L

W

 H

Net

Running

LBN-6T

30000

5

0.1

0.55

20

0.55

8300

DN65

2200

1000

1980

350

500

LBN-10T

50000

10

0.1

0.55

20

0.75

12500

DN65

2300

1000

2000

450

720

LBN-15T

75000

15

0.15

0.55

20

0.55x2

16600

DN65

2300

1000

1980

530

850

LBN-20T

100000

20

0.15

0.55

20

0.75x2

25000

DN65

2300

1000

2000

580

890

LBN-25T

125000

25

0.2

0.75

34

0.75x2

25000

DN80

2800

1250

2200

750

1520

LBN-30T

150000

30

0.2

0.75

34

1.1x2

31000

DN80

2800

1250

2200

830

1650

LBN-40T

200000

40

0.2

0.75

34

1.1x2

31000

DN100

2900

1250

2760

960

1650

LBN-50T

250000

50

0.25

1.1

60

1.5x2

36000

DN100

2900

1500

2760

1050

2080

LBN-60T

300000

60

0.25

1.1

60

1.5x2

36000

DN100

3000

1750

3000

1220

2260

LBN-70T

350000

70

0.3

1.5

87

1.1x4

50000

DN125

3200

2000

3000

1350

2720

LBN-80T

400000

80

0.3

1.5

87

1.1x4

50000

DN125

3200

2200

3000

1550

2980

LBN-100T

500000

100

0.3

2.2

100

1.5x4

72000

DN150

3600

2200

3000

1780

3080

LBN-125T

625000

125

0.3

2.2

100

1.5x4

72000

DN150

3600

2200

3220

1980

3280

LBN-150T

750000

150

0.3

2.2

100

2.2x4

100000

DN150

3660

2200

3380

2350

3980

LBN-180T

900000

180

0.3

4

100

5.5x4

146000

DN150

3900

2300

3420

2680

4650

LBN-200T

1000000

200

0.4

4

100

5.5x4

146000

DN150

4800

2300

3480

3180

4780

LBN-250T

1250000

250

0.4

2.2x2

200

7.5x2

162000

DN200

5200

2300

3680

4180

5570









2.2x2





162000

DN200

5500

2300

4210

4180

5570





























1. For medium frequency, high frequency power supply cooling
2.For medium-frequency quenching workpiece, if quenching liquid cooling
3.For vacuum heating, vacuum sintering, vacuum welding, vacuum melting furnace
4.For cooling of air compressors
5.For central air conditioning
6.For cooling of water-cooled screw machine and plate exchanger
7.For screw machines and other equipment
